This documentation is released under the Creative Commons licenseA basic Remote-Procedure-Call message
The following diagram shows usage relationships between types. Unresolved types are missing from the diagram. Click here to see the full picture.
The following diagram shows inheritance relationships for this type. Unresolved types are missing from the diagram. Click here to see the full picture.
| Name | Type | Description |
|---|---|---|
| BaseRpcMessage | packet |
A basic Remote-Procedure-Call message used for calls and return values |
| Name | Type | Description |
|---|---|---|
| BucketCall | packet |
requests a bucket from the destination node |
| CapReqCall | packet | (no description) |
| ChildCheckCall | packet | |
| ChildReleaseCall | packet | |
| CoordsOfNodeCall | packet |
Ping RPC Call asking for Coordinates |
| CoordsReqCall | packet |
RPC Call asking for Coordinates |
| DeBruijnCall | packet | (no description) |
| DHTdumpCall | packet |
Request to dump all local DHT records |
| DHTGetCall | packet | (no description) |
| DHTgetCAPICall | packet |
Message type to order the value corresponding to the OverlayKey key from the node responsible of key |
| DHTPutCall | packet | (no description) |
| DHTputCAPICall | packet |
Message type to store value at the keys root |
| DiscoveryCall | packet |
TODO generated message class |
| FailedNodeCall | packet |
A basic failed node notification |
| FindNodeCall | packet |
A basic find node rpc response |
| FixfingersCall | packet |
Message used to verify our ChordFingerTable |
| JoinCall | packet |
Message used to join a chord overlay |
| KbrTestCall | packet |
A basic find node rpc call |
| LookupCall | packet |
Internal RPC to ask overlay to start a lookup Author: Ingmar Baumgart |
| MyNeighborCall | packet | (no description) |
| NextHopCall | packet |
A next hop rpc call |
| NotifyCall | packet |
Message used to inform about existing predecessors |
| NTreeDivideCall | packet | (no description) |
| NTreeJoinCall | packet | (no description) |
| NTreePingCall | packet | (no description) |
| P2pnsRegisterCall | packet |
P2PNS Register RPC Call |
| P2pnsResolveCall | packet |
P2PNS Resolve RPC Call |
| ParentRequestCall | packet | |
| PastryJoinCall | packet | (no description) |
| PingCall | packet |
A basic ping rpc call |
| PubSubAdoptChildCall | packet | (no description) |
| PubSubBackupCall | packet | (no description) |
| PubSubHelpCall | packet | (no description) |
| PubSubIntermediateCall | packet | (no description) |
| PubSubJoinCall | packet | (no description) |
| PubSubPingCall | packet | (no description) |
| PubSubResponsibleNodeCall | packet | (no description) |
| PubSubSubscriptionCall | packet | (no description) |
| PubSubTakeOverSubspaceCall | packet | (no description) |
| RequestLeafSetCall | packet | (no description) |
| RequestRepairCall | packet | (no description) |
| RequestRoutingRowCall | packet | (no description) |
| RequestStateCall | packet | (no description) |
| RttToNodeCall | packet |
Ping RPC Call asking for RTT to Node |
| ScribeJoinCall | packet | (no description) |
| ScribePublishCall | packet | (no description) |
| StabilizeCall | packet |
Message used for the stabilization protocol as mentioned in "Chord: A Scalable Peer-to-Peer Lookup Protocol for Internet(1,2) Applications" |
| TreeAppCall | packet | (no description) |
| UnderlayTestCall | packet |
A basic rpc call for measuring underlay latencies |
| Name | Type | Description |
|---|---|---|
| nonce | unsigned int |
nonce to match RPC responses to corresponding calls |
| srcNode | NodeHandle |
source node |
| authBlock | AuthBlock[] |
optional authentication block containing a signature |
| type | int |
message type |
| statType | int |
message type for stats |
// // A basic Remote-Procedure-Call message // packet BaseCallMessage extends BaseRpcMessage { }
